Speedometer Tester

Speedometer Tester

Speedometer Tester

KCS Speeometer series

KCS Speedometer is designed to inspect the speed exactitude of a vehicle. Vehicle is able to running up to 120km/h on the roller of the tester, simulating the road condition without a real road test. All models of speedometer are robust build, in order to verify the accuracy of speedometer and odometer of vehicles,fitted with a fast pneumatic lifting system which could facilitate to drive out the vehicles.

Main Features

Speedometer Tester
Speedometer Tester

When testing the vehicle speedometer, drive the vehicle onto the tester and make sure the driving axle is on the rollers. The roller is driving by the wheels while accelerating the vehicle. The line velocity of roller is the same as that of vehicle wheels, which is the actual vehicle speed. The instant line velocity of roller will be measured and displayed by the instrument. By comparing the values of vehicle speedometer and the result of the instant speed, the deviation of the vehicle speedometer can be obtained.

Roller line velocity will be transformed from roller rotation speed into electric signal by sensors. After catching by the Instrument, it will be calculated and displayed as vehicle actual speed. The Central Lift, which set between rollers, is to assist the vehicle drive on/off the tester. The Pneumatic Control System is composing of electromagnetism valve and air cell.

  • Using of reinforced steel, strengthen and durable structure body;

  • High adhesion coating paint for long working life;

  • High precision sensor and high roundness of roller to ensurethe exactitude of result;

  • Roller brake pad system make sure the exit of vehicle;

  • 0-120km/h measurement range;

  • Wireless remote control;

  • Standard RS-232 connection port;

  • Air Lift bar;

  • 4 each Safety roller;

  • Can be integreated with 2 more equipment by VIS Control System;

  • Display Indicator (PC or LED indicator);

Specification

 Max Axle Load

KCS-10 (10t) / KCH-15 (15t)

 Measuring range

0 - 120km/h

 Display

LED Seven Segment

 Printer

Dotmatrix

 Structure type

KCS-10/KCS-15: Ø190x1100mm

 Power Supply

AC220V ±10%, 50Hz ±1%

 Roller Thread

405mm

 Air Supply

0.7-0.8Mpa

 Interface

RS232 Port

 Airlifting

6x Rubber Air Spring
